Using FHR

This guide shows one verified end-to-end example of adding FHR metadata to a FASTA file, explains how FHR and FHT differ, and answers common questions. All commands below were run against the released fhr package (0.3.3) and the synthetic example shipped with the converter; the sample is redistributable and its identifiers are placeholders.

Patterns across biology

A mosaic of scutes

A tortoise shell brings the pattern to a larger scale: its scutes form a mosaic of polygons, including near-hexagonal shapes.

The DNA connection behind our hexagon →

Prefer a form? The FHR table builder builds the metadata, validates it against the schema, and downloads the table and metadata file.

A worked example

Start with ordinary FASTA that carries no FHR metadata:

>chr1 synthetic example
ACGTACGTACGTACGT

Supply the metadata as a small YAML file (fields are described in the FHR specification):

schema: https://raw.githubusercontent.com/FAIR-bioHeaders/FHR-Specification/main/fhr.json
schemaVersion: 1.0
taxon:
  name: Homo sapiens
  uri: https://identifiers.org/taxonomy:9606
genome: Synthetic human reference example
version: 0.0.1
masking: not-masked
metadataAuthor:
- name: Adam Wright
  uri: https://orcid.org/0000-0002-5719-4024
assemblyAuthor:
- name: David Molik
  uri: https://orcid.org/0000-0003-3192-6538
dateCreated: '2022-03-21'

Install the released package and combine the metadata with the sequence:

python -m pip install fhr==0.3.3
fhr-fasta-combine metadata.yaml genome.fasta -o genome.fhr.fasta
fhr-fasta-validate genome.fhr.fasta

fhr-fasta-combine writes the metadata as ;~-prefixed header lines above the unchanged sequence, and fhr-fasta-validate confirms the metadata and the file checksum:

;~schema: https://raw.githubusercontent.com/FAIR-bioHeaders/FHR-Specification/main/fhr.json
;~schemaVersion: 1.0
;~taxon:
;~  name: Homo sapiens
;~  uri: https://identifiers.org/taxonomy:9606
;~genome: Synthetic human reference example
;~version: 0.0.1
;~masking: not-masked
;~metadataAuthor:
;~- name: Adam Wright
;~  uri: https://orcid.org/0000-0002-5719-4024
;~assemblyAuthor:
;~- name: David Molik
;~  uri: https://orcid.org/0000-0003-3192-6538
;~dateCreated: '2022-03-21'
;~checksum: PayVnq8Fdnzvaq2jOdUq+l0oJZ+iHk/DtiaYuUWRHqQ=
>chr1 synthetic example
ACGTACGTACGTACGT

To convert to another supported representation, use fhr-convert; it reads .json, .yaml, .fasta, .gfa, and .html from file extensions and validates before writing:

fhr-convert genome.fhr.fasta genome.fhr.json
fhr-validate genome.fhr.json

Scope: FHR, FHT, and where metadata lives

• FHR (FAIR Header Reference genome) describes reference genomes. FHT is a companion draft for reference transcriptomes; the two are separate specifications in the same family, and FHT is still draft.
• File-carried metadata travels with the sequence in ;~ (FASTA) or #~ (GFA) header comments, so the metadata cannot drift away from the data it describes. Repository metadata is held by the archive that stores the sequence; the two are complementary, not alternatives.
• FHR adds header comment lines only. Because those lines are comments, existing FASTA/GFA tooling continues to read the sequence unchanged — FHR does not require, and does not claim, special support from every tool.

Version compatibility

• The current FHR schema is schemaVersion: 1. Required fields and the version number have been stable across the 0.3 releases; new optional fields may be added over time.
• The released fhr Python package is version 0.3.3. Pin a version in automation and validate with fhr-validate or fhr-fasta-validate after writing files.
• Concept DOIs (for example the FHR Specification) group all releases of a resource. For a reproducible citation, use the version DOI for the specific release you used; see Resources & citation.

FAQ

How do I check an existing file? Run fhr-validate on JSON/YAML metadata, or fhr-fasta-validate / fhr-gfa-validate on sequence files to check both the metadata and the exact-byte checksum. Failures exit with status 1.

What happens if validation fails? The converter validates before writing, so an invalid entry is not written to the output path. Inspect the error, correct the metadata, and re-run.

Do I report schema problems or converter problems in the same place? No. Schema and specification questions belong with FHR-Specification; conversion and validation bugs belong with FHR-File-Converter.

Do I have to use the converter? No. The format is plain text; you can write or parse the ;~ header directly. The converter exists to make that easier and to validate against the schema.

Which citation should I use? Cite the published paper for a general description of FHR, and the version DOI of the specification or converter for direct use of a specific release. See Resources & citation.
